Wiring Harness Assemblies — Custom Interconnect Solutions
Wiring harness assemblies are organized bundles of wires, cables, and terminals that transmit electrical power and signals between different components within an electronic or electrical system. Unlike individual loose wires, a wiring harness secures and protects cables through bundling, sleeving, taping, or conduit — ensuring reliable, safe, and organized connections in complex assemblies.
Typical applications:
- Automotive and electric vehicle (EV) battery management systems
- Home appliances (washing machines, refrigerators, air conditioners)
- Industrial control panels and automation equipment
- Medical devices and diagnostic instruments
- LED lighting and display systems
- Robotics and motion control systems
Custom Manufacturing Capabilities — Built to Your Specification
| Parameter | What We Can Do |
|---|---|
| Electrical Definition | Fully customizable — voltage rating, current capacity, wire gauge selection, signal integrity requirements, and circuit configuration tailored to your application |
| Mechanical Definition | Fully customizable — harness outer diameter, bundle diameter, wire length, breakout points, and overall form factor designed for your specific routing and space constraints |
| Visual Definition | Fully customizable — wire color coding (per industry standards or custom), cable jacket color (any RAL/Pantone), print/legend (your logo, part number, or batch info), and stripe/marking patterns for easy identification |
| Wire Gauge (AWG) | 6 AWG to 32 AWG — power, signal, or hybrid configurations |
| Conductor Material | Tinned copper, bare copper, silver-plated copper, or aluminum |
| Insulation Material | PVC, XLPE, Teflon (PTFE), silicone, PE, or custom per requirement |
| Connector Options | Connector optional — choose from JST, Molex, AMP, TE, Hirose, Yazaki, Sumitomo, Deutsch, or supply your own connector for assembly; alternatively, we can terminate with bare ends, terminals, or lugs |
| Terminal Options | Crimp terminals (open/closed barrel), ring terminals, spade terminals, quick-disconnect tabs, or bullet terminals |
| Cable Bundling Method | Cable ties (nylon/velcro), spiral wrap, braided sleeving, heat shrink tubing, PVC tubing, or split conduit |
| Shielding | Unshielded, foil shield, braid shield, or combination — with braid density customizable per requirement |
| Protective Jacket | PVC, silicone, heat shrink, corrugated conduit, or flexible metal conduit |
| Length | Custom length as per your requirement — each wire individually cut to specified dimensions |
| Voltage Rating | Up to 600V (low voltage) / higher upon request |
| Temperature Range | -40°C to +150°C (based on insulation and jacket material) |
| Compliance | RoHS, REACH, UL recognized (file number available upon request) |
This list is for reference. If you have other requirements, inquire with us via WhatsApp, email, or online chat.
What We Customize — Down to Every Detail:
| Category | Customization Options |
|---|---|
| Electrical Definition | Wire gauge selection, current/power rating, signal pair routing, circuit configuration from scratch |
| Appearance | Wire color coding (per standard or brand-specific), cable jacket color (any RAL/Pantone), print legend (logo, text, barcode), heat shrink color and print |
| Physical Profile | Bundle diameter, individual wire length, breakout points (Y‑split or multi-branch), routing shape and form factor |
| Mechanical Build | Conductor material, insulation type, shielding level, bundling material, protective outer jacket |
| Connector & Termination | Connector optional — any brand/type (JST/Molex/TE/Deutsch/Yazaki/custom) or bare ends, ring terminals, spades, quick-disconnects, lugs |
| Protection & Strain Relief | Heat shrink, overmolding, grommets, strain relief boots, conduit, or gland fittings |
| Labeling & Identification | Cable markers, shrink tube labels, flag labels, QR/barcode tags for easy assembly and maintenance |
| Testing | 100% continuity, hi-pot (dielectric strength), insulation resistance, and pull-force testing upon request |
| Packaging | Reel, coil, spool, carton, or custom packaging per your shipping and kitting requirements |
Wiring Harness vs. Cable Assembly — What’s the Difference?
While often used interchangeably, there is a subtle distinction:
| Wiring Harness | Cable Assembly | |
|---|---|---|
| Construction | Multiple wires bundled together with outer protection (tape, sleeving, conduit) | Typically a single cable with connectors on both ends |
| Protection | More robust — heavy-duty sleeving, conduits, and protective covers | Simpler — usually just the cable jacket |
| Application | Complex routing across multiple components (e.g., automotive dashboards) | Point‑to‑point connections (e.g., display to motherboard) |
In short: Wiring harness = one or more cables/wires bundled as a system. Cable assembly = a single cable with connectors. We do both.
Simply put:
A wiring harness is the nervous system of any electronic device — it delivers power and data where they need to go, safely and reliably. We don’t just connect wires; we define every detail — from electrical ratings and connector selection to the color of every single wire and the print on the label — so your harness fits your application and your brand perfectly.
If you can draw it or describe it — we can build it.
30+ years of custom wiring harness experience. No minimum. No limitations.
